2026 SXS1000-3 Pioneer Deluxe |
2026 SXS1000-5 Pioneer Deluxe |
2025 Pioneer 1000-6 |
| Chassis |
| Brakes |
|
|
|
| Brakes (F) |
2x 210mm hydraulic disc |
2x 210mm hydraulic disc |
2x 210mm hydraulic disc |
| Brakes (R) |
2x 210mm hydraulic disc |
2x 210mm hydraulic disc |
2x 210mm hydraulic disc |
| Steering |
|
|
|
| Power Steering |
STD |
STD |
STD |
| Suspension |
|
|
|
| Front Adjustability |
- |
- |
n/a |
| Front Suspension Type |
Independent double-wishbone |
Independent double-wishbone |
Independent double-wishbone |
| Front Wheel Travel (mm) |
268 |
268 |
268 |
| Rear Adjustability |
preload |
- |
n/a |
| Rear Suspension Type |
Independent double-wishbone |
Independent double-wishbone |
Independent double-wishbone |
| Rear Wheel Travel (mm) |
255 |
255 |
254 |
| Dimensions, Weights And Capacities |
| Capacities |
30.5 |
30.5 |
30 |
| Dimensions |
|
|
|
| Bed Dumping Angle |
|
|
n/a |
| Turning Radius (m) |
4.7 |
4.7 |
4.75 |
| Wheelbase (mm) |
2,038 |
2,038 |
2,926 |
| Bed Height (mm) |
|
|
n/a |
| Bed Length (mm) |
|
|
n/a |
| Bed Width (mm) |
|
|
n/a |
| Ground Clearance (mm) |
350 |
329 |
320 |
| Overall Height (mm) |
2,034 |
2,018 |
1,933 |
| Overall Length (mm) |
3,025 |
3,020 |
3,866 |
| Overall Width (mm) |
1,625 |
1,625 |
1,600 |
| Seat Height (mm) |
|
|
850 |
| Weights |
|
|
|
| Bed/Tray Weight Capacity (kg) |
454 |
454 |
454 |
| Kerb Weight (kg) |
807 |
867 |
878 |
| Max Weight Capacity (kg) |
748 |
748 |
748 |
| Towing Capacity (kg) |
1,134 |
1,134 |
1,134 |
| Powertrain |
| Engine |
|
|
|
| Bore & Stroke (mm) |
92 x 75.1 |
92 x 75.1 |
92 x 75.15 |
| Compression Ratio |
10 : 1 |
10 : 1 |
10 : 1 |
| Cylinders |
Inline 2 |
Inline 2 |
Inline 2 |
| Displacement (cc) |
999 |
999 |
999 |
| Engine Type |
Liquid-cooled 4-stroke |
Liquid-cooled 4-stroke |
Liquid-cooled 4-stroke |
| Fuel System |
Fuel Injection |
Fuel Injection |
Fuel Injection |
| Starter |
Electric |
Electric |
Electric |
| Valves |
8 |
8 |
8 |
| Transmission |
|
|
|
| Drive Modes |
2WD, 4WD, 4WD Lock, Turf |
2WD, 4WD, 4WD Lock, Turf |
2WD, 4WD, 4WD Lock, Turf |
| Transmission |
6-speed DCT with reverse;
manual and automatic modes |
6-speed DCT with reverse;
manual and automatic modes |
6-speed with reverse;
manual and automatic modes |
| Drive |
Shaft |
Shaft |
Shaft |
| Tyres And Wheels |
| Tyres |
|
|
|
| Tyres (F) |
27x9-14 |
27x9-14 |
27x9-14 |
| Tyres (R) |
27x11-14 |
27x11-14 |
27x11-14 |
| Warranty |
| Warranty |
3 years |
3 years |
3 years |
