Goldwing Tour Premium |
Goldwing |
| Chassis |
| Brakes |
|
|
| Brakes (F) |
2x 320mm discs, ABS |
2x 320mm discs, ABS |
| Brakes (R) |
1x 316mm disc, ABS |
1x 316mm disc, ABS |
| Suspension |
|
|
| Front Adjustability |
- |
- |
| Front Suspension Type |
Double wishbone |
Double wishbone |
| Front Wheel Travel (mm) |
110 |
110 |
| Rear Adjustability |
preload (electronic) |
preload |
| Rear Suspension Type |
single shock |
single shock |
| Rear Wheel Travel (mm) |
105 |
105 |
| Dimensions, Weights And Capacities |
| Capacities |
|
|
| Fuel Capacity (L) |
21 |
21 |
| Dimensions |
|
|
| Wheelbase (mm) |
1695 |
1695 |
| Ground Clearance (mm) |
130 |
130 |
| Overall Height (mm) |
1430 low screen (1555 high screen) |
1340 low screen (1445 high screen) |
| Overall Length (mm) |
2575 |
2475 |
| Overall Width (mm) |
925 |
905 |
| Seat Height (mm) |
745 |
745 |
| Weights |
|
|
| Kerb Weight (kg) |
383 |
364 |
| Powertrain |
| Engine |
|
|
| Bore & Stroke (mm) |
73 x 73 |
73 x 73 |
| Compression Ratio |
10.5:1 |
10.5:1 |
| Cylinders |
6 |
6 |
| Displacement (cc) |
1833 |
1833 |
| Engine Type |
liquid-cooled 4-stroke |
liquid-cooled 4-stroke |
| Fuel System |
Fuel Injection |
Fuel Injection |
| Starter |
Electric |
Electric |
| Valves |
24 |
24 |
| Transmission |
|
|
| Transmission |
DCT 7-speed |
DCT 7-speed |
| Drive |
Shaft |
Shaft |
| Tyres And Wheels |
| Tyres |
|
|
| Tyres (F) |
130/70-18 |
130/70-18 |
| Tyres (R) |
180/60-16 |
180/60-16 |
| Warranty |
| Warranty |
24 months |
24 months |
