Compare up to 2 CMX1100 variants See the CMX1100 specifications below

  • CMX1100
    • CMX1100
    • CMX1100 DCT
  • CHOOSE VARIANT
    • CMX1100
    • CMX1100 DCT
CMX1100 CMX1100 DCT
Chassis
Brakes
Brakes (F) 1x 330mm disc, ABS 1x 330mm disc, ABS
Brakes (R) 1x 256mm disc, ABS 1x 256mm disc, ABS
Suspension
Front Adjustability Preload Preload
Front Suspension Type 43mm telescopic fork 43mm telescopic fork
Front Wheel Travel (mm) 121 121
Rear Adjustability Preload Preload
Rear Suspension Type twin shocks twin shocks
Rear Wheel Travel (mm) 95 95
Dimensions, Weights And Capacities
Capacities
Fuel Capacity (L) 13.6 13.6
Dimensions
Wheelbase (mm) 1,520 1,520
Ground Clearance (mm) 120 120
Overall Height (mm) 1,115 1,115
Overall Length (mm) 2,240 2,240
Overall Width (mm) 853 834
Seat Height (mm) 700 700
Weights
Kerb Weight (kg) 223 233
Powertrain
Engine
Bore & Stroke (mm) 92 x 81.5 92 x 81.5
Compression Ratio 10.1:1 10.1:1
Cylinders inline 2 inline 2
Displacement (cc) 1,084 1,084
Engine Type Liquid-cooled 4-stroke Liquid-cooled 4-stroke
Fuel System Fuel Injection Fuel Injection
Starter Electric Electric
Valves 8 8
Transmission
Transmission 6-speed DCT 6-speed
Drive Chain Chain
Tyres And Wheels
Tyres
Tyres (F) 130/70-18 130/70-18
Tyres (R) 180/65-16 180/65-16
Warranty
Warranty 24 months 24 months
