Compare up to 1 CB500 Hornet variants See the CB500 Hornet specifications below

  • CB500 Hornet
    • CB500 Hornet
CB500 Hornet
Chassis
Brakes
Brakes (F) 2x 296mm disc, ABS
Brakes (R) 1x 240mm disc, ABS
Suspension
Front Adjustability -
Front Suspension Type 41mm telescopic fork
Front Wheel Travel (mm) n/a
Rear Adjustability pre-load
Rear Suspension Type single shock
Rear Wheel Travel (mm) n/a
Dimensions, Weights And Capacities
Capacities
Fuel Capacity (L) 17.1
Dimensions
Wheelbase (mm) 1,410
Ground Clearance (mm) 145
Overall Height (mm) 1,060
Overall Length (mm) 2080
Overall Width (mm) 800
Seat Height (mm) 785
Weights
Kerb Weight (kg) 188
Powertrain
Engine
Bore & Stroke (mm) 67 x 66.8
Compression Ratio 10.7:1
Cylinders inline 2
Displacement (cc) 471
Engine Type Liquid-cooled 4-stroke
Fuel System Fuel Injection
Starter Electric
Valves 8
Transmission
Transmission 6-speed
Drive Chain
Tyres And Wheels
Tyres
Tyres (F) 120/70-17
Tyres (R) 160/60-17
Warranty
Warranty 24 months
