CB125 |
| Chassis |
| Brakes |
|
| Brakes (F) |
1 x 240mm disc |
| Brakes (R) |
1x 130mm drum |
| Suspension |
|
| Front Adjustability |
- |
| Front Suspension Type |
30mm telescopic fork |
| Front Wheel Travel (mm) |
108 |
| Rear Adjustability |
5 stage preload |
| Rear Suspension Type |
twin shocks |
| Rear Wheel Travel (mm) |
95 |
| Dimensions, Weights And Capacities |
| Capacities |
|
| Fuel Capacity (L) |
11 |
| Dimensions |
|
| Wheelbase (mm) |
1285 |
| Ground Clearance (mm) |
160 |
| Overall Height (mm) |
1091 |
| Overall Length (mm) |
2027 |
| Overall Width (mm) |
751 |
| Seat Height (mm) |
790 |
| Weights |
|
| Kerb Weight (kg) |
116 |
| Powertrain |
| Engine |
|
| Bore & Stroke (mm) |
50.0 x 63.1 |
| Compression Ratio |
10.0 : 1 |
| Cylinders |
1 |
| Displacement (cc) |
124 |
| Engine Type |
Air-cooled 4-stroke |
| Fuel System |
Fuel Injection |
| Starter |
Electric |
| Valves |
2 |
| Transmission |
|
| Transmission |
5-speed |
| Drive |
Chain |
| Tyres And Wheels |
| Tyres |
|
| Tyres (F) |
80/100-18 |
| Tyres (R) |
100/80-18 |
| Warranty |
| Warranty |
12 months |
