25YM XL750 Transalp |
23YM XL750 Transalp |
| Chassis |
| Brakes |
|
|
| Brakes (F) |
2x 310mm discs, ABS |
2x 310mm discs, ABS |
| Brakes (R) |
1x 256mm disc, ABS |
1x 256mm disc, ABS |
| Suspension |
|
|
| Front Adjustability |
preload |
preload |
| Front Suspension Type |
43mm inverted telescopic fork |
43mm inverted telescopic fork |
| Front Wheel Travel (mm) |
200 |
200 |
| Rear Adjustability |
preload |
preload |
| Rear Suspension Type |
single shock |
single shock |
| Rear Wheel Travel (mm) |
190 |
190 |
| Dimensions, Weights And Capacities |
| Capacities |
|
|
| Fuel Capacity (L) |
16.9 |
16.9 |
| Dimensions |
|
|
| Wheelbase (mm) |
1,560 |
1,560 |
| Ground Clearance (mm) |
210 |
210 |
| Overall Height (mm) |
1,455 |
1,450 |
| Overall Length (mm) |
2,325 |
2,325 |
| Overall Width (mm) |
838 |
838 |
| Seat Height (mm) |
850 |
850 |
| Weights |
|
|
| Kerb Weight (kg) |
210 |
208 |
| Powertrain |
| Engine |
|
|
| Bore & Stroke (mm) |
87 x 63.5 |
87 x 63.5 |
| Compression Ratio |
11:01 |
11:01 |
| Cylinders |
inline 2 |
inline 2 |
| Displacement (cc) |
755 |
755 |
| Engine Type |
liquid-cooled 4-stroke |
liquid-cooled 4-stroke |
| Fuel System |
Fuel Injection |
Fuel Injection |
| Starter |
Electric |
Electric |
| Valves |
8 |
8 |
| Transmission |
|
|
| Transmission |
6-speed |
6-speed |
| Drive |
Chain |
Chain |
| Tyres And Wheels |
| Tyres |
|
|
| Tyres (F) |
90/90-21 |
90/90-21 |
| Tyres (R) |
150/70-18 |
150/70-18 |
| Warranty |
| Warranty |
24 Months |
24 Months |
