CBR650R |
| Chassis |
| Brakes |
|
| Brakes (F) |
2x 310mm discs, ABS |
| Brakes (R) |
1x 240mm disc, ABS |
| Suspension |
|
| Front Adjustability |
- |
| Front Suspension Type |
41mm inverted telescopic fork |
| Front Wheel Travel (mm) |
108 |
| Rear Adjustability |
preload |
| Rear Suspension Type |
single shock |
| Rear Wheel Travel (mm) |
128 |
| Dimensions, Weights And Capacities |
| Capacities |
|
| Fuel Capacity (L) |
15.4 |
| Dimensions |
|
| Wheelbase (mm) |
1450 |
| Ground Clearance (mm) |
130 |
| Overall Height (mm) |
1,150 |
| Overall Length (mm) |
2,130 |
| Overall Width (mm) |
750 |
| Seat Height (mm) |
810 |
| Weights |
|
| Kerb Weight (kg) |
207 |
| Powertrain |
| Engine |
|
| Bore & Stroke (mm) |
67 x 46 |
| Compression Ratio |
11.6:1 |
| Cylinders |
Inline 4 |
| Displacement (cc) |
649 |
| Engine Type |
Liquid-cooled 4-stroke |
| Fuel System |
Fuel Injection |
| Starter |
Electric |
| Valves |
16 |
| Transmission |
|
| Transmission |
6-speed |
| Drive |
Chain |
| Tyres And Wheels |
| Tyres |
|
| Tyres (F) |
120/70-17 |
| Tyres (R) |
180/55-17 |
| Warranty |
| Warranty |
24 months |
