| CB750 Hornet | |
| Chassis | |
| Brakes | |
| Brakes (F) | 2x 296mm discs, ABS |
| Brakes (R) | 1x 240mm disc, ABS |
| Suspension | |
| Front Adjustability | n/a |
| Front Suspension Type | 41mm inverted telescopic fork |
| Front Wheel Travel (mm) | 130 |
| Rear Adjustability | preload |
| Rear Suspension Type | single shock |
| Rear Wheel Travel (mm) | 150 |
| Dimensions, Weights And Capacities | |
| Capacities | |
| Fuel Capacity (L) | 15.2 |
| Dimensions | |
| Wheelbase (mm) | 1,420 |
| Ground Clearance (mm) | 140 |
| Overall Height (mm) | 1,085 |
| Overall Length (mm) | 2,090 |
| Overall Width (mm) | 780 |
| Seat Height (mm) | 795 |
| Weights | |
| Kerb Weight (kg) | 192 |
| Powertrain | |
| Engine | |
| Bore & Stroke (mm) | 87 x 63.5 |
| Compression Ratio | 11:01 |
| Cylinders | 2 |
| Displacement (cc) | 755 |
| Engine Type | liquid-cooled 4-stroke |
| Fuel System | Fuel Injection |
| Starter | Electric |
| Valves | 8 |
| Transmission | |
| Transmission | 6-speed |
| Drive | Chain |
| Tyres And Wheels | |
| Tyres | |
| Tyres (F) | 120/70-17 |
| Tyres (R) | 160/60-17 |
| Warranty | |
| Warranty | 24 Months |
